Chamrider Battery is an ebike battery manufacturer and electric bicycle battery factory with 12 years of experience.

Electric Bicycle Battery Factory Chamrider Battery Brand Factory

Inquiry

Product details of the electric bicycle battery factory

Product Description

electric bicycle battery factory achieves excellent levels of detail. Our professional and skilled quality control personnel carefully check the production process of each step of the product to ensure that its quality is maintained without any defects. Dongguan Chamrider Technology Co., Ltd. continues to create value for customers, employees and all stakeholders.

Product Specification

Parameter 1

Parameter 2

Parameter 3

Parameter	36V20AH	36V22.5AH	36V25AH
Nominal Power	720Wh	810Wh	900wh
Configuration	10S5P	10S5P	10S5P
Cell Brand	ChamRider	ChamRider	Samsung
Cell Capacity	4000mah	4500mah	5000mah
Cell Type	21700
Built-in BMS	25A(Customized)
Fit Motor Power	24V250W-350W
APRX Weight（KG）	≈5.25	≈5.25	≈5.25
Dimension(mm)	410.298.579
Charge Current	1-5A
Life Cycle	≥80% Capacity After 500-800 cycles

Parameter	48V12AH	48V13.5AH	48V15AH
Nominal Power	576wh	648wh	720wh
Configuration	13S3P	13S3P	13S3P
Cell Brand	ChamRider	ChamRider	Samsung
Cell Capacity	4000mah	4500mah	5000mah
Cell Type	21700
Built-in BMS	25A(Customized)	30A(Customized)
Fit Motor Power	48V250W-500W	48V250W-1000W
APRX Weight（KG）	≈4.53	≈4.53	≈4.53
Dimension(mm)	410.298.579
Charge Current	1-5A
Life Cycle	≥80% Capacity After 500-800 cycles

Parameter	52V12AH	52V13.5AH	52V15AH
Nominal Power	624wh	702wh	780wh
Configuration	14S3P	14S3P	14S3P
Cell Brand	ChamRider	ChamRider	Samsung
Cell Capacity	4000mah	4500mah	5000mah
Cell Type	21700
Built-in BMS	20A(Customized)	25A(Customized)
Fit Motor Power	52V250W-350W	52V250W-500W
APRX Weight（KG）	≈4.73	≈4.73	≈4.73
Dimension(mm)	410.298.579
Charge Current	1-5A
Life Cycle	≥80% Capacity After 500-800 cycles

Product Introduction

Increased power

We've taken the power game to a whole new level with the SUONITE 21G52. Compared to its predecessor, the SUONITE 21G40, this cutting-edge model can accommodate 12 additional battery cells. This means more energy, more endurance and more power for your adventures.

Rugged aluminium-plastic casing

We understand the importance of durability when it comes to your battery. The SUONITE 21G52 has a rugged aluminium-plastic casing that provides exceptional shock resistance and maximum protection against accidental drops or rough handling. It's built to withstand the rigours of your outdoor activities.

Innovative 7-pin high current discharge port

Our team of experts developed a state-of-the-art 7-pin high-current discharge port exclusively for the SUONITE 21G52. This proprietary feature allows for faster and more efficient power delivery, ensuring you have a reliable source of power whenever you need it. Say goodbye to slow charging times and hello to fast power on demand.

Built-in mechanical latch for added security

We understand the need to keep your battery safe, especially in public places or when stored. The SUONITE 21G52 is equipped with a built-in mechanical locking system that provides an extra layer of protection against theft. Enjoy the peace of mind of knowing your battery is always safe and secure.

Five-level battery indicator

Stay informed and in control of your power usage with the SUONITE 21G52's intuitive five-step battery indicator. Whether you're on a thrilling mountain trail or navigating busy city streets, this feature allows you to accurately monitor your battery's remaining charge. Never again will you be surprised by a sudden power cut.

FAQ

Can e-bike batteries be used on rainy days?

Most e-bike batteries are waterproof and can be used in light rain. However, to ensure the safety and longevity of the battery, it is best to avoid prolonged exposure to heavy rain or immersion in water.

Does the e-bike battery support removability?

The majority of e-bike batteries feature a modular design, making them easily changeable and replaceable. However, the details may vary depending on the brand and model of the e-bike.

What is the weight of the e-bike battery?

The weight of e-bike batteries varies by brand, capacity, and material. Generally speaking, the weight of e-bike batteries usually ranges from a few kilograms to more than ten kilograms.

How do you choose the right type of e-bike battery for you?

Types of e-bike batteries include lithium-ion batteries, nickel-metal hydride batteries, and so on. Lithium-ion batteries have high energy density and small size and are the most commonly used type of e-bike battery.

Do e-bike batteries have safety protection?

Most e-bike batteries are equipped with multiple safety features, such as overcharge protection, over-discharge protection, over-current protection, etc., to ensure the safety of users and equipment.

Company Advantage

• Our company is close to the road with convenient transportation. It facilitates the transportation of products and guarantees the timely supply of products.
• Chamrider Battery constantly improves the service system and creates a healthy and excellent service structure.
• Founded in our company has always adhered to the development philosophy of 'quality-rooted, responsibility-based'. After years of hard work, we have won the recognition and praise from the market and consumers.
• Chamrider Battery established an excellent team by gathering numerous experienced personnel.
Chamrider Battery sincerely looks forward to your inquiry and cooperation!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
